Land Survey Target Square Mini Prism Optical Prism Reflector For Street Subsidence Monitoring Surveying
- Item No. : MPS002Y
Features & Applications
鈼 For building Monitoring or Mounting on a Street
鈼 Features & Benefits
鈼 Prisms with a 12.7 mm diameter in a wedge-shaped aluminum plate inserted
鈼 as well as to the edge of the road marking
鈼 Plate can be fixed with special adhesive to the pavement
鈼 Dimensions: 10 x 10 x 2.6 cm
- Inquiry now
Technical Specifications
|
Item |
Value |
|
Customized support |
OEM, ODM |
|
Place of Origin |
China |
|
Brand Name |
GEODEX |
|
Model Number |
MPS002Y |
|
Prism Diameter |
12.7mm |
|
Prism Constant |
0mm/17.8mm/23.1mm |
|
Product Size |
10cm(L)*10cm(W)*2.6cm(H) |
|
Measuring Range |
800m |
|
Net Weight |
365g |
|
Prism Material |
Optical Glass |
|
Prism Base Bracket |
Aluminum Alloy |
|
Prism Sides |
Single or dual-prism optional |
|
Used for |
Street Road monitoring surveying,Construction Site Prep, Mining, Tunneling, Rail Monitoring Prism Bolt |
|
Prism Bolt |
Available |
|
Color Available |
Yellow/Silver/Customization |
