Home > Surveying Levels > Laser Level > Automatic Rotating Laser Level land leveling measurement

Technical Specifications

Model	200HV(Red)	200HV(Green)	400HV(Red)	400HV(Green)
Work Range (Diameter)	500m Dia. (with detector)
Leveling Accuracy	±20"(± 1.0mm/10m)
Self-Leveling Range	±5°
Setting Slope	±5°(Dual axis:X,Y)		±10%(Dual axis:X,Y)
Light Source	Red Beam Laser Diode 635nm(visible) Class II Green Beam Laser Diode 532nm(visible) Class I
Display	Keypad Panel		LCD Screen Dual Sides
Spinning Speed	60, 120, 300,600r.p.m.
Directional Scanning Angle	10°,45°,90°,180°
Center Down Laser Point	±1.5mm/1m
Waterproof	IP 54
Operating Temperature	20℃ to +50℃(-4F to +122F)
instrument Size	160×160×185mm
instrument Net Weight	2.0kg		2.1kg
Power Supply	Four C/LR14 dry-cell battery		Rechargeable battery pack(Ni-MH)
Detector	LD-20R(Red Beam)	LD-20G(Green Beam)	LD-40R(Red Beam)	LD-40G(Green Beam)
Display	LCD Screen
BUzzer	ON/OFF
Icons for Warnings	Alert,Low Battery
Battery Level Indicator	LCD lcon
Power	9V(PPP3×1)6F22
Remote control	RC-20		RC-40
Work Range	20m
Power	2×AAA
